20' HARD SURFACE SCISSOR LIFT
110.00 5 HOURS 150.00 DAY 550.00 WEEK
| Work Height |
25' (7.6 m) |
| Raised Plat. Height (nom) |
19' (5.8 m) |
| Lowered Platform Height |
39" (0.99 m) |
| O/A Width |
32" (0.81 m) |
| O/A Length |
70" (1.78 m) |
| Stowed Height (rails up) |
78.5" (1.99 m) |
| Stowed Height (rails down) |
OPT. (64.5", 1.64 m) |
| % Gradeability |
23 |
| Platform Size (inside dimension) |
26" x 64" (0.66 m x 1.63 m) |
| Capacity* Lbs (kg) |
550lbs(249kb) |
| Travel speed mph (km/h) |
2 mph (3.2 km/h) |
| Lift time (sec) |
25 |
| Weight * Lbs (kg) |
2580 lbs (1,170 kg) |
|  | 27' ALL TERRAIN SCISSOR LIFT
150.00 5 HOURS 250.00 DAY 750.00 WEEK
|
Model
|
7127
|
| Work Height |
33' (10.1 m)
|
| Raised Plat. Height (nom) |
27' (8.2 m)
|
| Lowered Platform Height |
60.5'' (1.54 m) |
| O/A Width |
71.5'' (1.82 m)
|
| O/A Length |
127'' (3.23 m)
|
| Stowed Height (rails up) |
105.5'' (2.68 m)
|
| Stowed Height (rails down) |
77'' (1.96 m) |
| % Gradeability |
30 |
| Platform Size (inside dimension) |
64" x 116.5" (1.62 x 2.96 m)
|
| Capacity* Lbs (kg) |
1,500 lb (680 kg)
|
| Travel speed mph (km/h) |
3 mph (4.8 km/h)
|
| Lift time (sec) |
31
|
| Weight * Lbs (kg) |
8,200 lb (3,720 kg) |
|
|
|
 |
|
|
|
|
 |
|
