BILJAX 43' MANLIFT
150.00 5 HOURS 205.00 DAY 695.00 WEEK
Long battery duty cycles for hours of operation in multi-shift conditions and smooth controls combined with fast lift and drive speeds providing improved productivity for the operator, add up to excellent productivity. |
|
|
|
|
| |
|
Additional Advantages
- Hydraulic Outriggers for added stability
- Proporational controls provide smooth operation
- 110v outlet at the platform
- Outrigger LED display located on the lower controls, indicates when each outrigger is properly set, allowing for quick set up and ease of use.
|
|
|
| |
|
|
|
Specifications
|
| Rated Platform Load |
450 lbs (204 kg) |
| Max Work Height |
43 ft (13.1 m) |
| Extended Basket Height |
37 ft (11.3 m) |
| Elevation Rate, Nominal |
5.3 in/sec (135 mm/sec)
[26.7 ft/min (8.14 m/min] |
| Horizontal Reach |
19 ft (5.9m) |
| Boom Rotation |
700° |
| Rotation Speed |
318° per minute, nominal |
| Basket Dimensions |
51 in. W x 30 in. D x 45 in. H
(129.5 cm x 76 cm x 114.3 cm) |
| Power Source |
24 Volt DC, 4 Deep Cycle,
245 Amp-hour Battery |
| Battery Charger |
110/120 Volt, 40 Amp |
| Hydraulic Pressure |
2756 psi |
| Gross Vehicle Weight |
2860 lbs (1297 kg) |
| Tongue Weight |
100 lbs (45.4 kg) |
| Trailer Brakes |
Mechanical Surge |
| |
|
|
|
|
 |
|
|
|
|
 |
|
